TP-Link

TP-Link Omada AP EAP225, WIFI5, AC1350, 3x3, 1 GbE, Inomhus

Artikelnummer: EAP225
Leveranstid: Obekräftat
Datablad
Samtidiga 450 Mbps på 2,4 GHz och 867 Mbps på 5 GHz ger totalt 1317 Mbps Wi-Fi-hastigheter Stöder sömlös roaming så att även videoströmmar och röstsamtal inte påverkas när användare flyttar mellan platser Gratis molncentraliserad hantering och Omada-app för ex... läs mer
1 044 kr
Ord. pris 1 099 kr
  • Samtidiga 450 Mbps på 2,4 GHz och 867 Mbps på 5 GHz ger totalt 1317 Mbps Wi-Fi-hastigheter
  • Stöder sömlös roaming så att även videoströmmar och röstsamtal inte påverkas när användare flyttar mellan platser
  • Gratis molncentraliserad hantering och Omada-app för extrem bekvämlighet och enkel hantering
  • Kompatibilitet med 802.3af och passiv PoE (PoE-adapter ingår) gör implementeringen enkel och flexibel
  • Säkert gästnätverk tillsammans med flera autentiseringsalternativ (SMS/Facebook Wi-Fi/ Voucher, etc.) och riklig trådlös säkerhetsteknik.
  • Bandstyrning flyttar automatiskt dubbla bandenheter till det bredare 5GHz-bandet för snabbare anslutningar
  • MU-MIMO innebär åtkomstpunkter som samtidigt överför data med flera enheter, vilket påskyndar anslutningar
  • Beamforming koncentrerar signalen dit du behöver den mest, vilket ger en snabb och stabil Wi-Fi-upplevelse
  • Schema kan ställas in så att åtkomstpunkter automatiskt startar om och Wi-Fi slås på/av vid de tider du väljer
HARDWARE FEATURES
Interface Gigabit Ethernet (RJ-45) Port *1 (Support IEEE802.3af PoE and Passive PoE *)
Physical Security Lock Yes
Button Reset
Power Supply 802.3af/at PoE
24V Passive PoE (+4,5pins; -7,8pins. PoE Adapter Included)
Power Consumption EU: 10.5 W
US: 12.6W
Dimensions ( W x D x H ) 8.1 × 7.1 × 1.5 in (205.5 × 181.5 × 37.1 mm)
Dimensions 8.1 × 7.1 × 1.5 in. (205.5 × 181.5 × 37.1 mm)
Antenna Type 3 Internal Omni *
2.4GHz: 4dBi
5GHz: 5dBi
Mounting Ceiling /Wall Mounting (Kits included)
Hardware Watch Dog Yes
WIRELESS FEATURES
Wireless Standards IEEE 802.11ac/n/g/b/a
Frequency 2.4GHz and 5GHz
Signal Rate 5GHz:Up to 867Mbps
2.4GHz:Up to 450Mbps *
Wireless Functions Multiple SSIDs (Up to 16 SSIDs, 8 for each band)
Enable/Disable Wireless Radio
Automatic Channel Assignment
Transmit Power Control (Adjust Transmit Power on dBm)
QoS(WMM)
Band Steering
Load Balance
MU-MIMO *
Airtime Fairness *
Beamforming *
Rate Limit
Reboot Schedule
Wireless Schedule
Wireless Statistics based on SSID/AP/Client
Wireless Security Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
Transmission Power CE:
≤20dBm(2.4GHz,EIRP)
≤23dBm(5GHz,EIRP)
FCC:
≤24dBm(2.4GHz)
≤22dBm(5GHz)
MANAGEMENT
Omada App Yes
Centralized Management • Omada Hardware Controller OC300
• Omada Hardware Controller OC200
• Omada Software Controller
• Omada Cloud-Based Controller (Supported by EAP225 V3.0, V4.0 and above, and is not supported by EAP225 V3.20)
Cloud Access Yes, through
• OC300
• OC200
• Omada Software Controller
• Omada Cloud-Based Controller (Supported by EAP225 V3.0, V4.0 and above, and is not supported by EAP225 V3.20)
EAP Controller Software Yes
Email Alerts Yes
LED ON/OFF Control Yes
Management MAC Access Control Yes
SNMP v1,v2c
System Logging Local/Remote Syslog Local/Remote Syslog
Telnet Yes
SSH Yes
Web-based Management HTTP/HTTPS
L3 Management Yes
Multi-site Management Yes
Management VLAN Yes
Zero-Touch Provisioning Yes. Requiring the use of Omada Cloud-Based Controller (Supported by EAP225 V3.0, V4.0 and above, and is not supported by EAP225 V3.20)
OTHERS
Certification CE, FCC, RoHS
Package Contents AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point EAP225
Passive PoE Adapter
Power Cord
Mounting Kits
Installation Guide
System Requirements Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Linux
Environment Operating Temperature: 0℃~60℃ (32℉~144℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
HARDWARE FEATURES
Interface Gigabit Ethernet (RJ-45) Port *1 (Support IEEE802.3af PoE and Passive PoE *)
Physical Security Lock Yes
Button Reset
Power Supply 802.3af/at PoE
24V Passive PoE (+4,5pins; -7,8pins. PoE Adapter Included)
Power Consumption EU: 10.5 W
US: 12.6W
Dimensions ( W x D x H ) 8.1 × 7.1 × 1.5 in (205.5 × 181.5 × 37.1 mm)
Dimensions 8.1 × 7.1 × 1.5 in. (205.5 × 181.5 × 37.1 mm)
Antenna Type 3 Internal Omni *
2.4GHz: 4dBi
5GHz: 5dBi
Mounting Ceiling /Wall Mounting (Kits included)
Hardware Watch Dog Yes
WIRELESS FEATURES
Wireless Standards IEEE 802.11ac/n/g/b/a
Frequency 2.4GHz and 5GHz
Signal Rate 5GHz:Up to 867Mbps
2.4GHz:Up to 450Mbps *
Wireless Functions Multiple SSIDs (Up to 16 SSIDs, 8 for each band)
Enable/Disable Wireless Radio
Automatic Channel Assignment
Transmit Power Control (Adjust Transmit Power on dBm)
QoS(WMM)
Band Steering
Load Balance
MU-MIMO *
Airtime Fairness *
Beamforming *
Rate Limit
Reboot Schedule
Wireless Schedule
Wireless Statistics based on SSID/AP/Client
Wireless Security Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
Transmission Power CE:
≤20dBm(2.4GHz,EIRP)
≤23dBm(5GHz,EIRP)
FCC:
≤24dBm(2.4GHz)
≤22dBm(5GHz)
MANAGEMENT
Omada App Yes
Centralized Management • Omada Hardware Controller OC300
• Omada Hardware Controller OC200
• Omada Software Controller
• Omada Cloud-Based Controller (Supported by EAP225 V3.0, V4.0 and above, and is not supported by EAP225 V3.20)
Cloud Access Yes, through
• OC300
• OC200
• Omada Software Controller
• Omada Cloud-Based Controller (Supported by EAP225 V3.0, V4.0 and above, and is not supported by EAP225 V3.20)
EAP Controller Software Yes
Email Alerts Yes
LED ON/OFF Control Yes
Management MAC Access Control Yes
SNMP v1,v2c
System Logging Local/Remote Syslog Local/Remote Syslog
Telnet Yes
SSH Yes
Web-based Management HTTP/HTTPS
L3 Management Yes
Multi-site Management Yes
Management VLAN Yes
Zero-Touch Provisioning Yes. Requiring the use of Omada Cloud-Based Controller (Supported by EAP225 V3.0, V4.0 and above, and is not supported by EAP225 V3.20)
OTHERS
Certification CE, FCC, RoHS
Package Contents AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point EAP225
Passive PoE Adapter
Power Cord
Mounting Kits
Installation Guide
System Requirements Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Linux
Environment Operating Temperature: 0℃~60℃ (32℉~144℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
