Qubino Flush Shutter DC
Qubino Flush Shutter DC
Qubino Flush Shutter DC
Qubino

Qubino Flush Shutter DC

Article no.: ZMNHOD1
Availability: 5st
Radio control module for regulation of roller blinds and awnings. Can be connected to three-wire electrical systems. Qubino Roller Shutter can control motor curtains and awnings steplessly, this applies to both motors with electronic and mechanical limit positions. This is done e... read more
599 kr
Quantity discount Unit price Incl Tax You save
2 or more 541 kr 116:-
4 or more 535 kr 256:-
6 or more 529 kr 420:-
10 or more 523 kr 760:-

Radio control module for regulation of roller blinds and awnings. Can be connected to three-wire electrical systems. Qubino Roller Shutter can control motor curtains and awnings steplessly, this applies to both motors with electronic and mechanical limit positions. This is done either via Z-wave (smartphone/tablet)* or via the switch connected to it.

Can be controlled wirelessly via e.g. Home Center 2 with associated iOS or Android application.

*requires gateway e.g. Home Center

Built-in modules (Qubino Roller Shutter) are placed behind the existing switches and do not affect the appearance of the installation. To know if you can install these without running extra cables, you must first investigate if you have so-called Neutral conductor (zero) behind the switch, this is in most cases blue. The total number of cables behind the switch must be at least 3, then we do not count Earth (green/yellow).

Should you not have the Neutral conductor pulled forward, your electrician will do this without major problem.

Once this is done the installation is painless, existing switch is simply connected to the built-in module (Qubino Roller Shutter), reassemble the whole installation and put the cover on. After that, you should be able to use the switch to regulate the electrical device as usual, if you have installed a Roller Shutter, you can also steplessly operate the roller blind alt. the awning with the button.

Now if we want to add the device to a Z-wave network, i.e. connect it to a gateway e.g. Home Center or similar. This is to achieve the function of controlling the built-in module (Qubino Roller Shutter) via the mobile alt. via a scenario. So you don't need a gateway to control it with the power switch, this can always be done, but to control the built-in module (Qubino Roller Shutter 24VDC) via the phone, we need a gateway.

Write a review

What is Z-Wave Plus?

Z-Wave Plus™ is a certification developed to help users identify products that use the "new generation" also known as the "500 series" of Z-Wave hardware. Z-Wave Plus™ offers a bunch of extra functions and possibilities that improve your use and make the installation of Z-Wave devices easier.

Z-Wave has been the market leader in interoperable smart home devices since 2004. With the introduction of Next-Gen (Z-Wave 500 series) hardware, Z-Wave saw new opportunities, including longer range, longer battery life, Over The Air upgrade (OTA), more RF channels and much more. All this and they are backwards compatible with existing Z-Wave devices.

For consumers, home owners, integrators and service providers, this upgrade turned out to be very beneficial in terms of much easier installation, richer device profiles, improved self-healing and longer battery life.

Features:

  • 50% Longer battery life
  • 67% Longer range
  • 250% More Bandwidth
  • 3 F channels for improved interference protection and higher bandwidth
  • New Plug-n-Play network-wide inclusion process
  • Improved self-healing and fault tolerance with Explorer Frame function
  • Standardized method for Over the Air firmware updates (OTA)
  • Improved information for the product certification database

To be sure what is Z-Wave Plus certified, note this image above the product images on our website (Z-Wave Plus)

Kompatibilitetslistan uppdateras ganska ofta men fel kan förekomma. Hittar du något som är felaktigt så meddela oss gärna så att vi kan ändra!

Controller Status Kommentar
ZNet Lite V2 Enheten fungerar helt och hållet
Home Center HC3 Enheten fungerar helt och hållet i HC2 och HCL
Zipabox Enheten fungerar inte helt och hållet
