Amit IDG500-0T501 4G LTE Router GbE + WAN Dual SIM Router

Article no.: IDG500-0T501
Delivery time: Est. delivery 7d
AMIT IDG500-0T501 - competent and reliable 4G router with dual SIM card, Gigabit LAN/WAN port and GPS. Adapted for applications in industry, retail POS, digital signage and with support for 4G/WAN fail-over. Safety The IDG500-0T501 is very safe and equipped with features to a... read more
3 109 kr

AMIT IDG500-0T501 - competent and reliable 4G router with dual SIM card, Gigabit LAN/WAN port and GPS. Adapted for applications in industry, retail POS, digital signage and with support for 4G/WAN fail-over.

Safety
The IDG500-0T501 is very safe and equipped with features to automatically reconnect to the internet, mobile or via landline, no matter what happens. It also has a built-in hardware and software watch dog that can break the voltage to both the radio module and the SIM card. This is to ensure a trouble-free reconnection in the event of any operational disruptions at the operator.

Gigabit LAN/WAN
Equipped with 2 RJ45 Gigabit Ethernet LAN ports, one of which can be configured such as WAN.

Durable design
Constructed in a stable metal shell to withstand harsher environments and working temperatures (-30 to +70 degrees).

Flexible administration
Web interface is used for basic settings. Programmable CLI and Command Script are used for advanced configuration.

Smart Event Management
The IDG500 has a built-in mechanism to perform actions on predefined events. These are triggered or notified based on system/status change, SMS, SNMP trap or email.

VPN
The router has built-in VPN support for IPSec, L2TP, PPTP (client-/server-mode), GRE, L2TP over IPSec and OpenVPN. The router handles a maximum of 3 tunnels up to approx. 20 Mbps throughput.

Flexible power supply
The IDG500-0T501 is supplied with an AC adapter, but the router can be powered via the included adapter with unstabilized DC - the 5-18V supply.

Dual SIM
The router has dual SIM card slots to be able to connect to two different operators, for example on different physical networks. Switching takes place automatically in the event of any operational problems.

Fail-over
The IDG500-0T501 has built-in fail-over between the Ethernet WAN port and mobile 4G. Choose between DSL/fiber or 4G as the primary internet connection in the event of operational disruptions. In addition, it has the option of using both 4G and the WAN port at the same time (Load Balancing) for those occasions when you want to maximize traffic capacity.

SMS handling
The IDG500-0T501 has built-in support for SMS. The SMS function can be used to administer the router (status, connect, disconnect, reconnect and reboot) or to alert.

Dynamic DNS
Built-in support for a number of various dynamic DNS services. For example DynDNS.org and No-IP.com.

Routing protocols
The IDG500-0T501 has built-in support for static routing tables and dynamic routing protocols such as RIP, OPSF and BGP.< /p>

Transparent mode
The router can be configured in transparent mode if you want to place it outside the existing firewall as a 4G modem.

Configurable frequency band
In the IDG500-0T501, you can choose which frequency bands the router is allowed to communicate on. You can e.g. choose only 3G or 4G depending on how mobile coverage is at the location.

GPS
The router has built-in support for GPS positioning via GNSS, NMEA 0183. The data can then be sent to server or stored locally.

Integrated storage
The IDG500-0T501 has the ability to store large amounts of data on MicroSD (max 64Gb, not included). Ex. Script, configurations and GPS data.

FTP
The router has a built-in FTP server. For sharing and storing data directly on the device.

Key features:

  • 4G LTE module with dual SIM cards
  • < li>Gigabit Ethernet WAN port and 4G redundancy for extra high operational security
  • GPS positioning
  • Software and hardware watch dog
  • Integrated storage with microSD.< /li>
  • Built-in load balancing for multiple WANs (Ethernet + 4G)
  • Transparent mode for placement outside existing firewall
  • VPN support for IPSec, OpenVPN, PPTP and L2TP up to 3 tunnels with max. 20Mbps throughput (IPSec).

Write a review

Explanation of frequency bands

When choosing an antenna, pay attention to which frequency bands the antenna supports. Depending on which operator and where the antenna will be used, the frequency bands vary. Larger cities use 2600MHz while smaller towns use 800/900MHz with some support bands in between such as 1800/2100MHz.

A higher frequency band gives a higher speed but also has a shorter range. The same applies to the antenna, if you have a base station that transmits on 2600MHz, your antenna, antenna cable and the location of the antenna become more important than on a lower frequency band. Explanation of signal loss we will go through soon. Higher frequency bands also mean shorter range from the base station.

450MHz (coverage band) also known as the Net1 band is the frequency band that covers the most area in Sweden. Therefore, Net1 is known to be able to have reception where other operators don´t have a chance, but with low download and upload speeds. The reason why this band is called Net1 is because that the company Net1 has exclusive rights to this frequency band.

800MHz (coverage band) is used by all common operators, excluding Net1. The low frequency band means that 800MHz covers a lot of space. Therefore, the band is used outside big cities or smaller towns. 800MHz is the most used frequency band around Europe.

900MHz (coverage band) is the band that Tele2 and Telenor initially used as coverage band. 900MHz is a more unusual LTE band and in the beginning the band caused some problems when the clients (mobile phones etc.) could not connect to 900MHz. Today, the mobile phone manufacturers have adapted the mobile phones to be able to communicate on 900MHz.

1800MHz (capacity band) is the latest frequency band launched. All operators today use this band in metropolitan centers (apart from Net1).

2600MHz (capacity band) is a very well-used frequency band all over Europe. 2600MHz is the highest frequency band used for LTE, this means that the band also has the shortest range compared to 800/900MHz. Due to the high capacity, the band is used in metropolitan environments where many base stations are required to cover as much surface as possible and have as high a capacity as possible.

Frekvensplan 4G

Frequency band Net1 Tele2 Telia Telenor Tre
450MHz (Band 31)
800MHz (Band 20)
900MHz (Band 8)
1800MHz (Band 3)
2600MHz (Band 38)
