Sunricher

Drivdon Z-wave 30W 250-1000mA - Dimbar - Constant Current

Artikelnummer: SRP-ZV9105-30CC
Lagersaldo: 3st - Passa på
This is a 30W Dimmable LED Driver with 1 channel constant current output and adjustable current from 250mA to 1000mA using DIP switches on the driver. It is designed with 200-240VAC input. Power factor of the driver can be over 0,9 and efficiency is hither than 83%. It enables sm... läs mer
550 kr

This is a 30W Dimmable LED Driver with 1 channel constant current output and adjustable current from 250mA to 1000mA using DIP switches on the driver. It is designed with 200-240VAC input. Power factor of the driver can be over 0,9 and efficiency is hither than 83%. It enables smooth and deep dimming to 0,1% without flickering and buzzing noise. The driver is designed with Z-Wave Plus control interface which can be included to Z-Wave network and be controlled from your controller or hub interface. The driver can be compatible with universal Z-Wave gateway or primary controller. In addition, the Z-wave device can bind with Z-wave remote or wall controllers and be controlled by them.

Key features:

- Dimmable LED Driver, Max output power 30W
- 1 channel constant current output and adjustable current from 250mA to 1000mA
- Class II Power Supply, full isolated plastic case
- Rubycon capacitors
- Built-in active PFC function
- High power factor and efficiency, PF > 0,9, Efficiency > 83%
- Z-Wave Plus control interface which can be included to Z-Wave network and be controlled from your controller or hub interface
- To switch and dim single colour LED lighting
- Smooth and deep dimming to 0,1% without flickering, no buzzing noice
- IP20 rating, suitable for indoor LED lighting applications

Please note:

Max output voltage is 48V. Due to this restriction you won't achive maximum effect in all configurations. Please refer to the table below for some examples:

Current Max effect
250mA 12W
350mA 16,8W
550mA 26,4W
700mA 30W
1000mA 30W

Specifikationer

  • Tillverkare: Sunricher
  • Användning: till LED-lampor 250-1000mA (ställbar i steg om 50mA)
  • Effekt: 30W
  • Utspänning : 8-48V DC
  • Matarspänning: 200-240V AC
  • Utvändiga mått: 53,4 x 170 x 28mm
Spänning: 230V AC 50Hz
Mått:(BxDxH) 53,4 x 170 x 28mm
Z-Wave Plus Ja
Min effekt (W) 30
Max effekt (W) 30
Typ av montering Inbyggd
