Ubiquiti

EdgePoint WISP Router 5xGE ports 1xSFP port

Ubiquiti Networks introduces the EdgePoint™, part of the EdgeMAX® platform. The first application-specific designed WISP control point, the EdgePoint combines EdgeMAX routing features with fiber backhaul and versatile powering capabilities. Breakthrough in Tower Deployment ... läs mer
Artikelnummer: EP-R6
Leveranstid: 2-3 Dagar
Fri frakt
1 699 kr

Ubiquiti Networks introduces the EdgePoint™, part of the EdgeMAX® platform. The first application-specific designed WISP control point, the EdgePoint combines EdgeMAX routing features with fiber backhaul and versatile powering capabilities.

Breakthrough in Tower Deployment
The EdgePoint features FiberProtect to significantly reduce electrostatic discharge (ESD) failures and electromagnetic interference (EMI), greatly improve data signal integrity, and consolidate the wired data backhaul to a single fiber cable run for long-distance connectivity.

All-in-One Design
A single, compact controller efficiently eliminates clutter, expensive cabinets, extraneous installations, and excessive maintenance.

Robust Construction
The ruggedized case withstands outdoor conditions, including wind, rain, and snow. The included cable sleeve protects the cables and cable opening. If you prefer, you can swap it out for your own conduit.

Advanced Applications
For the EP-R6, powerful routing features – such as load balancing and failover– provide redundancy and increased performance for outdoor wireless links.

Versatile Power Options
Powered by 24VDC or by PoE, the EP-R6 can support 24V passive PoE to power most Ubiquiti products.

Intuitive User Interface
The EdgePoint features a graphical user interface designed for convenient setup and control. Accessed via a network port and web browser, the user-friendly interface provides intuitive management with a virtual view of the ports, displaying physical connectivity, speed, and status.

Depending on whether you are configuring a router or switch, the configuration interface will differ.

Routing Configuration
The EP-R6 offers robust features, including:

  • VLAN interfaces for network segmentation
  • Static routes and support of routing protocols: OSPF, RIP, and BGP
  • Firewall policies and NAT rules
  • Application identification with Deep Packet Inspection (DPI)
  • DHCP services
  • Quality of Service (QoS)
  • Network administration and monitoring tools
  • Administrator and operator accounts
  • Comprehensive IPv6 support

Switching Configuration
The EP-S16 provides advanced features, including:

  • MSTP/RSTP/STP
  • VLAN, Private VLAN, Voice VLAN
  • Link Aggregation
  • DHCP Snooping, IGMP Snooping
  • TACACS+, RADIUS, 802.1X, MAC Filtering, ACL
  • DiffServ, CoS
  • Static Routing, Policy-Based Routing

Configuration by CLI
The CLI provides quick and flexible configuration by command line and features the following:

  • For power users, configuration and monitoring of all advanced features
  • Direct access to standard Linux tools and shell commands

CLI access through the following:

  • Serial console port
  • SSH
  • Telnet
  • Graphical user interface
Teknisk Specifikation
Anslutningsteknik Kabelansluten
Bredd 18.86 cm
Datalänkprotokoll Ethernet, Fast Ethernet, Gigabit Ethernet
Djup 4.98 cm
Energiförbrukning vid drift 7 Watt
Flash-minne 256 MB
Funktioner Brandväggsskydd, Nivå 3-växling, NAT-stöd, ström via Ethernet (PoE), VLAN-stöd, IGMP snooping, dynamisk DNS-server, Stöd för DiffServ, MAC-adressfiltrering, stöd för IPv6, stöd för STP (Spanning Tree Protocol), stöd för RSTP (Rapid Spanning Tree Protocol), stöd för MSTP (Multiple Spanning Tree Protocol), DHCP-snooping, stöd för Access Control List (ACL), Quality of Service (QoS), IPv4-support, statisk routing, Link Aggregation
Gränssnitt 1 x Ethernet 1000 - SFP (mini-GBIC)
Gränssnitt 5 x 10Base-T/100Base-TX/1000Base-T (PoE) - RJ-45
Höjd 17.71 cm
Luftfuktighet vid drift 10 - 90 % (icke-kondenserade)
Max temperatur vid drift 60 °C
Medföljande OS Ubiquiti EdgeOS
Min temperatur vid drift -40 °C
Modell Pålmonterbar
Nätspänning Likström 24 V
Nätverks/transportprotokoll PPTP, L2TP, IPSec, PPPoE
Nätverksprotokoll OSPF, RIP, BGP, IGMP, GRE, OSPFv3, RIPng
Processor 1 x MIPS MIPS 1004Kc 880 MHz
Protokoll för administration på distans SNMP, Telnet, HTTP, SSH, CLI
RAM 256 MB DDR3 SDRAM
Service och support Begränsad garanti - 1 år
Standarder som följs IEEE 802.1Q, IEEE 802.3ad (LACP), IEEE 802.1x, IC, FCC
Statusindikatorer Portstatus, strömförsörjning, PoE, länk/akvititet
Typ av enhet Router
Verifieringsmetod RADIUS, TACACS+
Vikt 605 g
Teknisk Specifikation
Anslutningsteknik Kabelansluten
Bredd 18.86 cm
Datalänkprotokoll Ethernet, Fast Ethernet, Gigabit Ethernet
Djup 4.98 cm
Energiförbrukning vid drift 7 Watt
Flash-minne 256 MB
Funktioner Brandväggsskydd, Nivå 3-växling, NAT-stöd, ström via Ethernet (PoE), VLAN-stöd, IGMP snooping, dynamisk DNS-server, Stöd för DiffServ, MAC-adressfiltrering, stöd för IPv6, stöd för STP (Spanning Tree Protocol), stöd för RSTP (Rapid Spanning Tree Protocol), stöd för MSTP (Multiple Spanning Tree Protocol), DHCP-snooping, stöd för Access Control List (ACL), Quality of Service (QoS), IPv4-support, statisk routing, Link Aggregation
Gränssnitt 1 x Ethernet 1000 - SFP (mini-GBIC)
Gränssnitt 5 x 10Base-T/100Base-TX/1000Base-T (PoE) - RJ-45
Höjd 17.71 cm
Luftfuktighet vid drift 10 - 90 % (icke-kondenserade)
Max temperatur vid drift 60 °C
Medföljande OS Ubiquiti EdgeOS
Min temperatur vid drift -40 °C
Modell Pålmonterbar
Nätspänning Likström 24 V
Nätverks/transportprotokoll PPTP, L2TP, IPSec, PPPoE
Nätverksprotokoll OSPF, RIP, BGP, IGMP, GRE, OSPFv3, RIPng
Processor 1 x MIPS MIPS 1004Kc 880 MHz
Protokoll för administration på distans SNMP, Telnet, HTTP, SSH, CLI
RAM 256 MB DDR3 SDRAM
Service och support Begränsad garanti - 1 år
Standarder som följs IEEE 802.1Q, IEEE 802.3ad (LACP), IEEE 802.1x, IC, FCC
Statusindikatorer Portstatus, strömförsörjning, PoE, länk/akvititet
Typ av enhet Router
Verifieringsmetod RADIUS, TACACS+
Vikt 605 g
