Ubiquiti

UniFi Switch 8 GE ports PoE 60W 4 ports with PoE

Build and expand your network with Ubiquiti Networks® UniFi® Switch, part of the UniFi line of products. The new 8-port models feature Gigabit Ethernet ports in a compact form factor. The switches are fully manageable, delivering robust performance and intelligent switch... läs mer
Artikelnummer: US-8-60W
Lagersaldo: 1st
Redo för omgående leverans.

1 490 kr

Build and expand your network with Ubiquiti Networks® UniFi® Switch, part of the UniFi line of products.

The new 8-port models feature Gigabit Ethernet ports in a compact form factor. The switches are fully manageable, delivering robust performance and intelligent switching for your networks.

Switching Performance
The UniFi Switch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.

For its total, non-blocking throughput, each UniFi Switch supports up to 8 Gbps with a switching capacity of 16 Gbps.

PoE
The US-8 can be powered by 802.3af/at, 48V passive PoE, or the included power adapter. When the US-8 is powered by 802.3at PoE or the included power supply, port 8 supports 48V (2-pair) PoE passthrough to deliver up to 12W of power.

The following table displays the PoE passthrough options for the US-8:

Power Input PoE Passthrough
802.3af In No PoE Out
802.3at In 802.3af Out
Power Supply (Included) 48V Passive Out

The US-8-60W is powered by its included power adapter. It has four auto-sensing PoE ports delivering up to 15.4W of power per port.

  • Model: US-8-60W
  • (8) Gigabit RJ45 Ports
  • (4) Auto-Sensing IEEE 802.3af PoE Ports
  • Non-Blocking Throughput: 8 Gbps
  • Switching Capacity: 16 Gbps
  • Forwarding Rate: 11.9 Mpps
  • Maximum Power Consumption: 12W



Skriv ut produktsidan

Specification
Dimensions 148.0 x 99.5 x 30.7 mm (5.83 x 3.92 x 1.21")
Weight 432 g (15.24 oz)
Enclosure Characteristics SGCC Steel
Total Non-Blocking Throughput 8 Gbps
Switching Capacity 16 Gbps
Forwarding Rate 11.9 Mpps
Max. Power Consumption 12W (Excluding PoE Output)
Max. PoE Wattage per Port 15.4W
Power Method 48VDC, Max. 2A
Supported Voltage Range 57VDC to 44VDC
Power Supply External AC/DC Adapter, 48V, 1.25A
LEDs PoE (Port 8), Speed/Link/Activity (All Ports)
Sound Level* 0.6 dBr (Fanless)
Networking Interfaces (8) 10/100/1000 Mbps RJ45 Ports
PoE Interfaces (4) Ports 5, 6, 7, 8; IEEE802.3af
ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV
Operating Temperature -5 to 45° C (23 to 113° F)
Operating Humidity 5 to 95% Noncondensing
Shock and Vibration ETSI300-019-1.4 Standard
Certifications CE, FCC, IC
